Drive Controllers R911298372 HCS02.1E-W0070-A-03-NNNN Compact Converter Operating a Servo Motor

The converters in the IndraDrive C series generate a DC bus voltage from the supply voltage and convert it into a controlled AC
output voltage of variable amplitude and frequency for operating a servo motor. The compact design includes additional mains
connection components and is therefore particularly suited for single-axis applications.

The converters in the IndraDrive Cs series also come with an integrated control unit. * Compact design for single-axis
applications2.5x overload capacity

Technical Specs

Product attributesCooling typeinternal air coolingMaximum current [A]70.8Continuous current [A]28.0Width [mm]105Height [mm]251.5
Depth [mm]352International protection codeIP20Nominal mains frequency [Hz]50-60Maximum power (without choke) [kW]14Continuous
power (without choke) [kW]9Max. power (with power choke) [kW]19Continuous power (with power choke) [kW]14max. output frequency (@4
kHz switching frequency) [Hz]0-400max. output frequency (@8 kHz switching frequency) [Hz]0-800max. output frequency (@12 kHz
switching frequency) [Hz]0-1200max. output frequency (@16 kHz switching frequency) [Hz]0-1600Power supply voltage (1 AC) [V]
200-250Power supply voltage (3 AC) [V]200-500Output voltage3 x AC 0 … Mains connection voltage VWeight [kg]7.4
