Rexroth LC Series Logic Valve | LC16 LC25 LC40 LC63 | LC63B20E6X
| Model Number | LC80DB00D6X/, LC63DB40A7X, LC63B40E6X, LC63B40D6X, LC63B20E6X |
|---|
Product Description
LIC Hydraulic offers the Rexroth LC Series 2-Way Cartridge Valves, the powerhouse of modern manifold-based hydraulic systems. These “Logic Valves” conform to ISO 7368 standards and are available in nominal sizes from LC16 up to LC100. The LC series consists of a seat valve insert—comprising a spool, spring, and seals—combined with a control cover. Whether you require simple directional control or complex pressure modulation, models like LC63B40D6X and LC80DB00D6X deliver unmatched flow rates and leak-free performance for the most demanding heavy-duty applications.
Technical Specifications (Quick Reference)
Standard Sizes: LC16, LC25, LC32, LC40, LC50, LC63, LC80, LC100.
Max Operating Pressure: Up to $350\text{ bar}$ ($5000\text{ PSI}$).
Flow Capacity: Size-dependent, reaching several thousand liters per minute at LC80/100 sizes.
Cracking Pressures: Various spring ratings (e.g., $2.0\text{ bar}, 4.0\text{ bar}$ indicated by “20” or “40” in the code).
Key Technical Advantages
Massive Power Density: The cartridge design allows for significantly higher flow velocities with minimal pressure drop compared to conventional spool valves.
Hermetic Sealing: Utilizing a poppet-and-seat design, these valves provide absolute shut-off, making them ideal for load-holding and safety circuits.
Dynamic Customization: By changing the control cover, the same LC insert can perform different functions (e.g., relief, sequence, or directional control), offering immense flexibility in manifold design.
High Reliability: Designed for millions of cycles under high-pressure conditions, the robust construction ensures minimal maintenance and downtime.
Application Areas
Heavy Presses: Used for pre-fill, main cylinder control, and rapid decompression.
Die Casting & Injection Molding: High-speed movement control for large-scale clamping and injection units.
Energy & Metallurgy: Critical fluid control in turbine governors and steel mill rolling stands.
Expert Maintenance Tips
Cavity Inspection: When replacing an LC63 insert, inspect the manifold cavity for “steps” or scratches. Any imperfection can bypass the seals, leading to mysterious system pressure drops.
Orifice Verification: Most logic functions depend on the small orifices (nozzles) inside the control cover. Ensure these are not clogged. A single grain of debris can cause the valve to “hang” open or closed.
Torque Specs: Always follow the manufacturer’s torque sequence for the four cover bolts. Uneven tightening can warp the cover or the insert, leading to erratic spool movement or premature seal failure.
