Parker PD060 PD045 PD100 Piston Pump | PD060PC02SRS5AAM0E1200000 | PD060AM289073

Model Number	PD060PC02SLS5BC00E1200000, PD060PC02SRS5AAM0E1200000

Product Description

LIC Hydraulic’s Parker P1/PD Series axial piston pumps set the benchmark for high-density power in open-circuit applications. This series, covering PD045, PD060, and PD100, is engineered for severe duty cycles in both mobile and industrial environments. We provide 100% Drop-in Interchangeability for high-precision configurations like PD060PC02SRS5AAM0E1200000 and specialized units like PD060AM289073. Featuring a robust cast-iron housing and a noise-damping design, these pumps deliver a continuous 280 bar (4060 PSI) with class-leading volumetric efficiency and whisper-quiet performance.

Technical Specifications (Bulleted List)

Displacements: 45cc, 60cc, 100cc (Full range available).
Specific P/Ns: PD060PC02SRS5AAM, PD060PC02SLS5BC, PD060AM289073.
Nominal Pressure: 280 bar (4060 PSI).
Peak Pressure: 320 bar (4640 PSI).
Rotation: Right-hand (S) or Left-hand (L) configurations.
Features: Pressure Compensator, Load Sensing, and Torque Limiting options.

Key Technical Advantages

Whisper-Quiet Technology: The “ripple chamber” housing design reduces fluid-borne noise and pressure ripples, making it ideal for urban mobile equipment and indoor industrial power units.
High Power Density: Compact footprint allows for easier integration in modern, space-constrained engine compartments without compromising flow capacity.
Enhanced Bearing Life: Utilizing oversized bearings to handle high radial loads, ensuring maximum uptime even in high-vibration applications.
Fast Response Controls: The internal swashplate mechanism offers ultra-fast response times, facilitating precise power management and significantly reducing fuel consumption.

Application Areas

Heavy Duty Mobile: Main hydraulics for compactors, loaders, and auxiliary circuits for excavators.
Industrial Automation: Powering injection molding machines, metal presses, and trash compactors.

Expert Maintenance Tips

Verify Rotation Code: Always cross-reference the rotation code (S vs L) on your existing pump. Installing a PD060PC…SLS where an SRS is required will result in immediate failure of the internal timing and shaft seal.
Case Drainage: Ensure the case drain line returns directly to the reservoir and stays below the oil level. High case backpressure is the #1 cause of premature seal failure.
Initial Priming: Never start the pump dry. Fill the case with clean, filtered hydraulic oil through the drain port before initial startup to protect the piston shoes and swashplate from friction damage.

model list:

PD140PM04SRS5AC00S0000000 02E-84937-5
05E-01158-5 PD140PM04SRS5BC00S0000000
05E-1529-5 PD140PS02SRS5BAM0S1000000
05E-01235-5 PD140PS02SRS5BC00S100000
02E-82487-5 PD140PS02SRS5AC00S1000000
PD060PA02SRS5AC00S0000000
PD060PM04SRS5BC00S0000000
PD045PS02SRS5AAN0E0000000
PD060PS02SRS5AAM0S1000000 02E-85927-5
PD060PC02SRS5AC00E1200000
PD140PB04SRS5AAN0S100PB00
PD060PA02SRS5AC00S0000000
PD028PA02SRS5AC00R0200000
PD140PS02SRS5AAM0S1000000 02E-82953-5
PD060PC02SRS5AC00E1200000
PD100PA02SRS5AL0TS1000000
PD060PD02SRS5AC00E1400000
PD060PD02SLS5AC00E1400000
PD140PS02SRS5ACOOS100 02E-82487-5
PD100PS02SRS5ARHOS100 02E-83887-5
02E-82843-5 PD075PS02SRS5AC00E0000000
PD060PC02SRS5AC00E1200000
PD140PB04SRS5ASD2S100PB00
PD045PS02SRS5AAN0E0000000
PD140PS02SRS5AAN0S00
PD060PS02SRS5BC00S0000000
PD018PB04SRS5BC00E1200000
PD018PB04SRS5BC00R0200000
PD028PA02SRS5BAM0R1000000 05E-01842-5
PD028PA02SRS5BAM0T00A0000 05E-01843-5
PD028PA02SRS5BAM0T02A0000 05E-01844-5
PD028PA02SRS5BC00E1000000 05E-01845-5
PD028PA02SRS5BC00R0200000 05E-01846-5
PD028PA02SRS5BC00R1200000 05E-01847-5
PD028PA02SRS5BC00R120PB00
PD028PS02SRS5BC00E0200000
PD028PS02SRS5BC00E1000000 05E-01941-5
PD028PS02SRS5BC00E100PB00 05E-01942-5
PD028PS02SRS5BC00E1200000 05E-01943-5
PD028PS08SRS5BC00R1000000 05E-01986-5
PD028PS08SRS5BC00R1200000 05E-01987-5
PD028PS08SRS5BC00T00APB00 05E-01988-5
PD045PA02SRS5AAN0E0000000 02E-87955-5
PD045PA02SRS5BAM0R1000000 05E-02353-5
PD045PA02SRS5BL00E120PB00 05E-02363-5
PD045PA02SRS5BL00R1000000 05E-02364-5
PD045PM04SRS5AALTT00A0000 02E-99983-5
PD045PM04SRS5BAM0R1000000
PD045PM04SRS5BAM0T00BPB00 05E-02401-5
PD018PA02SRS5BC00E0200000 05E-00385-5
PD018PA02SRS5BC00R0200000
PD018PA02SRS5BC00R020PB00
PD018PA02SRS5BC00R1200000 05E-00386-5
PD018PA02SRS5BL00E3200000 05E-00225-5
PD018PA04SRS5BC00R1200000
PD018PA04SRS5BC00R120PB00 05E-02017-5
PD018PA04SRS5BC00T02HPB00
PD018PA04SRS5BL00E0200000 05E-00388-5
PD018PA06SLS5BL00R0200000 05E-00389-5
PD045PM04SRS5BC00R0000000 05E-02404-5
PD045PS01SRU5AAM0R0000000 02E-85898-5
PD045PS01SRU5AAM0R0200000 02E-87538-5
PD060PA02SRS5BC00E0000000 05E-02914-5
PD060PA02SRS5BC00E1000000 05E-02915-5
PD060PA02SRS5BC00S0000000 05E-02916-5
PD060PA02SRS5BC00S1000000
PD060PA02SRS5BL00S0000000
PD060PA02SRS5BL00S1000000
PD060PA02SRS5BL00T00C0000
PD060PA04SRS5AALTS0000000 02E-86950-5
PD060PC01SRS5BAM0T00B0000 05E-02953-5
PD060PC01SRS5BC00E1200000 05E-02954-5
PD060PC01SRS5BC00S1000000 05E-02955-5
PD060PC01SRS5BC00T00B0000 05E-02956-5
PD060PC01SRS5BL00E1200000 05E-02957-5
PD060PC01SRS5BL00T00APB00 05E-02958-5
PD060PC02SLS5AAMTS1000000 02E-87992-5
PD060PS01SLS5BC00E1000000 05E-03032-5
PD060PS02SLS5BL00S0000000 05E-03081-5
PD060PS02SLS5BL00S1000000
PD060PS02SLU5AAM0E0200000 02E-87051-5
PD060PS02SLU5AC00S0000000 02E-88871-5
PD060PS02SRU5AAM0T00H0000 02E-87187-5
PD060PS02SRU5AAM0T00K0000 02E-85766-5
PD060PS02SRU5AAM0T10A0000 02E-89823-5
PD060PS02SRU5AAN0S1000000 02E-88575-5
PD060PS02SRU5AAN0T00A0000 05E-00244-5
PD075PA02SRS5AL00E1000000 02E-84973-5
PD060PS01SLS5BC00S0000000 05E-03033-5
PD060PS01SLS5BC00S1000000 05E-03034-5
PD060PS01SLS5BL00E0000000
PD060PS01SLS5BL00E1000000 05E-03036-5
PD060PS01SLS5BL00S0000000 05E-03037-5
PD060PS01SLS5BL00S1000000 05E-03038-5
PD060PS01SLS5BL00S100PB00 05E-03039-5
PD060PS02SLS5BC00E1000000 PD060PA02SRS5AC00E0000000
PD060PA02SRS5AC00S1000000
PD060PA04SRS5AALTS0000000
PD060PB04SRS5AAM0S0000000
PD060PB04SRS5AAM0S000PB00
PD060PB04SRS5AC00S0000000
PD060PB04SRS5AC00S100PB00
PD060PB04SRS5AL00S0000000
PD060PB04SRS5AL00S1000000
PD060PB04SRS5AL20S100PB00
PD060PC01SRS5AC00S1000000
PD060PC02SLS5AAM0T00H0000
PD060PC02SLS5AC00E1200000
PD060PC02SLS5AL00E1200000
PD060PC02SRS5AAM0E1200000
PD060PC02SRS5AAM0S1000000
PD060PC02SRS5AAMTE120PB00
PD060PC02SRS5AC00E1000000
PD060PC02SRS5AC00E1200000
PD060PC02SRS5AC00S0000000
PD060PC02SRS5AC00S1000000
PD060PC02SRS5AC00T00C0000
PD060PC02SRS5AC10T00B0000
PD060PD01SLS5AC00E1400000
PD060PD01SLS5AL00E1400000
PD060PD01SRS5AAM0E1400000
PD060PD01SRS5AC00E1400000
PD060PD01SRS5AC00S1000000
PD060PD01SRS5AL00E1400000
PD060PD02SLS5AC00E1400000
PD060PD02SRS5AALTE1400000
PD060PD02SRS5AAM0E1400000
PD060PD02SRS5AAMTE1400000
PD060PD02SRS5AC00E0000000
PD060PD02SRS5AC00E1400000
PD060PD02SRS5AC00S1000000
PD060PD02SRS5AL00E0000000
PD060PD02SRS5AL00E1400000
PD060PM04SRS5AC00S0000000
PD060PM04SRS5AC00S1000000
PD060PS01SLS5AC10E1000000
PD060PS01SRS5AAM0E0000000
PD060PS01SRS5AC00S100PB00
PD060PS01SRS5AL00S100PB00
PD060PS02SLS5AALTE0000000
PD060PS02SLS5AC10E1000000
PD060PS02SRS5AAF0S1000000
PD060PS02SRS5AAM0S0000000
PD060PS02SRS5AC00E0000000
PD060PS02SRS5AC00E100PB00
PD060PS02SRS5AC00S1000000
PD060PS02SRS5AC00S110PB00
PD060PS02SRS5AC00T00A0000
PD060PS02SRS5AC10E1000000
PD060PS02SRS5AC10S1000000
PD060PS02SRS5AL00E1000000
