Parker PV Series Axial Piston Pump | PV040 PV063 PV092 PV140 | PV040R1K1T1NMR1
| Model Number | PV04OR1K1T1NMR1, PV040R1K1T1NMR1 |
|---|
Product Description
LIC Hydraulic presents the Parker PV Series, the gold standard for heavy-duty industrial hydraulic power. Ranging from PV016 to PV360, these axial piston variable displacement pumps are engineered for continuous high-pressure operation (up to 350 bar). Models like the PV040R1K1T1NMR1 feature Parker’s patented pre-compression volume technology, which significantly minimizes pressure ripples and vibration. Built with robust cast iron housings and oversized bearings, the PV series is the preferred choice for forging presses, steel mills, and marine systems. Our PV units offer 100% original interchangeability, ensuring maximum uptime with guaranteed volumetric efficiency.
Technical Specifications (Bulleted List)
Series: Parker PV Series (Axial Piston Variable Displacement)
Displacement Range: $16\text{ cm}^3\text{/rev}$ to $360\text{ cm}^3\text{/rev}$
Nominal Pressure: $350\text{ bar}$ ($5000\text{ PSI}$)
Peak Pressure: $420\text{ bar}$ ($6000\text{ PSI}$)
Controls: Pressure Compensator, Load Sensing, Electronic Controls (NMR, L, etc.)
Mounting: Metric and SAE Flange standards available
Drive: 100% Thru-Drive capability for multiple pump tandems
Key Technical Advantages
Quiet Operation: The integrated pre-compression volume reduces flow pulsation and noise emissions by up to $50\%$, making it ideal for indoor factory environments.
Maximum Fatigue Resistance: The use of heavy-duty spherical piston-shoe assemblies and reinforced swashplate bearings allows for high cycle frequencies under peak load.
Energy-Efficient Controls: Modular compensators allow for precise energy management, reducing heat generation by matching pump output exactly to the system’s demand.
Serviceability: The internal design allows for straightforward maintenance and parts replacement, ensuring the pump can be refurbished to OEM standards even after years of heavy use.
Application Areas
Metal Forming: High-pressure hydraulic presses and CNC bending machines.
Heavy Industrial: Primary drives for paper mills and scrap metal balers.
Marine & Offshore: Winch power units and rudder control systems.
Expert Maintenance Tips
Initial Priming: Always fill the pump housing with filtered hydraulic oil via the highest drain port before starting the prime mover. Never dry-run the pump.
Drain Line Management: Ensure the case drain line is oversized and free of restrictions. High case pressure is the primary cause of shaft seal blowout and internal component lift-off.
Filtration Integrity: To protect the precision-ground valve plates, maintain a cleanliness level of ISO 4406 18/15/13 or higher. Regularly monitor for metallic particles in the return filters.
