Eaton Char-Lynn 100 & 162 Series High Speed Motor | 158-4130-001 162-1009-004 | Hydraulic Orbital Motor
| Model Number | 162-1009-004, 162-1016-004, 158-4130-001 |
|---|
Product Description
LIC Hydraulic’s Eaton Char-Lynn 100 Series (Models 101, 103, 104, 105, 106, 109) and 162 Series high-speed orbital motors are the ultimate choice for applications requiring rapid rotation and compact integration. Utilizing advanced Gerotor technology, these motors are engineered to deliver industry-leading speeds of up to 5,000 RPM. We offer 100% Drop-in Interchangeability for global B2B supply, matching OEM part numbers like 158-4130-001, 162-1009-004, and 162-1016-004. To guarantee reliability in high-cycle environments, every unit undergoes 100% simulated load testing, ensuring perfect dynamic balance and peak volumetric efficiency at maximum speeds.
Technical Specifications (Bulleted List)
Model Series: Char-Lynn 100 Series (High Speed) / 162 Series
OEM Part Numbers: 158-4130-001, 162-1009-004, 162-1016-004
Displacement Range: 7.4 cm³/rev to 49.2 cm³/rev
Continuous Pressure: 105 bar (1500 PSI)
Intermittent Pressure: 140 bar (2000 PSI)
Maximum Speed: Up to 5000 RPM (100 Series) / 3400 RPM (162 Series)
Max Flow Rate: 38 L/min to 75 L/min
Shaft Options: 1-inch Straight Keyed, Splined, or Tapered (SAE Standard)
Housing Material: Die-cast Aluminum or High-tensile Iron
Approx. Weight: 1.5 kg to 3.2 kg (Ultra-compact design)
Key Technical Advantages
Superior High-Speed Stability: Optimized Gerotor geometry and precision-timed valve plates allow for smooth operation above 3,000 RPM with minimal vibration and noise.
Three-Piece Modular Design: This high-precision construction minimizes internal leakage and provides excellent thermal shock resistance, ideal for applications with rapid temperature fluctuations.
Enhanced Bearing Support: Integrated high-capacity needle bearings or specialized bushings handle centrifugal forces and radial loads, significantly extending the drive shaft’s fatigue life.
Rapid Dynamic Response: The low-inertia design enables millisecond reversals and quick start/stop cycles, perfect for precision automation and high-frequency actuation.
Application Areas
Turf & Agriculture: Mower deck drives, small blowers, and seeder mechanisms.
Industrial Maintenance: Street sweeper brush drives and winch auxiliary systems.
Factory Automation: High-speed conveyor drives and power tool integration.
Expert Maintenance Tips
Avoid Overspeeding: Always adhere to the maximum flow rate for your specific displacement. Overspeeding causes cavitation, which can lead to premature pitting of the Gerotor set.
Viscosity Management: Due to high operational speeds, use premium hydraulic fluids with a viscosity of 32-46 cSt. Excessive viscosity at high RPM can generate parasitic heat.
Case Drain Protocol: For systems with high back pressure, always utilize the case drain port to protect the shaft seal and maintain optimal internal pressure.
