Char-Lynn 2000 Series Replacement Motor | 104-1018-006 | 104-1020-006
| Model Number | 104-1022-0061, 104-1021-006, 104-1020-006, 104-3440-006, 104-1018-006, 104-3938-006 |
|---|
Product Description
LIC Hydraulic offers premium replacement motors for the Char-Lynn (Eaton) 2000 Series, a proven industry leader in medium-duty orbital motor technology. These motors leverage Geroler® technology to deliver higher mechanical efficiency and smoother low-speed operation compared to standard gerotor designs. Models like 104-1018-006 and 104-1022-006 are built to endure high back pressures and heavy radial loads, making them the standard choice for professional-grade agricultural and construction equipment.
Key Technical Features
High Volumetric Efficiency: The precision-engineered Geroler® set maintains consistent performance throughout the life of the motor.
Robust Drive Link: The heavy-duty internal drive link provides extra durability during frequent reversals and high shock loads.
Industry Standard Mounting: Direct drop-in replacement for Eaton 2K series, ensuring zero downtime during maintenance.
Versatile Porting: Standard 7/8-14 UNF (O-ring) ports ensure a leak-free connection.
Expert Maintenance Tips
Case Drain Management: For applications with high back pressure or frequent direction changes, we recommend using the external case drain port to maximize shaft seal life.
Rotation Check: Verify your system’s flow direction. The -006 design typically supports bi-directional rotation, but ensure your valve configuration matches the motor’s intended porting.
Oil Cleanliness: To protect the precision Geroler rollers, maintain filtration at ISO 18/16/13 or better.
model list：
104-3955-006
104-3995-006
104-3997-006
104-4001-006
104-4004-006
104-4013-006
104-4022-006
104-4027-006
104-4032-006
104-4041-006
104-4042-006
104-4046-006
104-4076-006
104-4114-006
104-4117-006
104-4130-006
104-4152-006
104-4156-006
104-4161-006
104-4163-006
104-4168-006
104-4174-006
104-4187-006
104-4194-006
104-4199-006
104-4200-006
104-4201-006
104-4202-006
104-4212-006
104-4214-006
104-4246-006
104-4260-006
104-4295-006
104-4298-006
104-4299-006
104-4301-006
104-4306-006
104-4307-006
104-4314-006
104-4315-006
104-4332-006
104-4334-006
104-4338-006
104-4352-006
104-4361-006
104-4364-006
104-4365-006
104-4366-006
104-4367-006
104-4370-006
104-4390-006
104-4399-006
104-4400-006
104-4401-006
104-4402-006
104-4410-006
104-4411-006
104-4416-006
104-4432-006
104-4470-006
104-4478-006
104-4484-006
104-4538-006
104-4544-006
104-4576-006
104-3278-006
104-3279-006
104-3300-006
104-3302-006
104-3320-006
104-3328-006
104-3342-006
104-3343-006
104-3345-006
104-3347-006
104-3358-006
104-3367-006
104-3387-006
104-3390-006
104-3394-006
104-3399-006
104-3400-006
104-3402-006
104-3425-006
104-3428-006
104-3431-006
104-3438-006
104-3440-006
104-3442-006
104-3447-006
104-3458-006
104-3469-006
104-3471-006
104-3484-006
104-3490-006
104-3497-006
104-3498-006
104-3505-006
104-3523-006
104-3524-006
104-3526-006
104-3527-006
104-3531-006
104-3538-006
104-3548-006
104-3568-006
104-3569-006
104-3578-006
104-3586-006
104-3589-006
104-3594-006
104-3595-006
104-3613-006
104-3616-006
104-3625-006
104-3639-006
104-3642-006
104-3650-006
104-3662-006
