SV Series Solenoid Cartridge Valve | SV3-10 SV1-8 SV2-8 | SV3-10-C-0-24DG
| Model Number | SV2-8-4M-0-24DGS, SV3-10-0-0-12DW, SV1-8-4-0-24DGS, SV3-10-C-0-24DG |
|---|
Product Description
LIC Hydraulic’s SV Series solenoid threaded cartridge valves are the building blocks of modern hydraulic manifold systems. Available in SV1, SV2, and SV3 sizes, these valves offer precise on-off or directional control within a highly compact footprint. We provide 100% Drop-in Interchangeability for industry-standard part numbers like SV3-10-C-0-24DG, SV1-8-4-0-24DGS, and SV3-10-0-0-12DW. Built with hardened steel spools and cages, every SV valve is tested to withstand continuous duty at 3000+ PSI, ensuring high-cycle reliability for aerial lifts, agriculture machinery, and industrial HPUs.
Technical Specifications (Bulleted List)
Series Framework: SV1 (2-Way), SV2 (2-Way High Flow), SV3 (3-Way), SV4 (4-Way).
Cavity Sizes: 8 (3/4-16 Thread) and 10 (7/8-14 Thread).
Pressure Rating: Continuous $210\text{ bar}$ ($3000\text{ PSI}$); Peak up to $350\text{ bar}$.
Flow Capacity: From $23\text{ L/min}$ (Size 8) to $45\text{ L/min}$ (Size 10).
Voltage Options: 12VDC, 24VDC, 110VAC, 220VAC.
Coil Termination: DIN 43650 (G), Deutsch (DT04), Lead Wires (W).
Key Technical Advantages
Precision Machined Steel Components: The hardened spool-and-sleeve design ensures minimal internal leakage and provides exceptional resistance to abrasive particles in the fluid.
High-Speed Switching: Optimized electromagnetic actuators allow for millisecond-level response times, critical for synchronized hydraulic movements and safety interlocks.
Modular Manual Override: Available with various manual override options (Push, Twist, or Screw type), allowing for emergency system operation during power loss.
Rugged Coil Design: Encapsulated coils are designed for high-temperature stability and are rated up to IP67 protection against moisture and dust ingress.
Application Areas
Aerial Work Platforms: Steering, lifting, and safety lockout circuits for scissor and boom lifts.
Agricultural Implements: Directing flow for planters, harvesters, and tractor attachments.
Compact HPUs: Ideal for integrated manifold blocks used in small industrial presses and power units.
Expert Maintenance Tips
Proper Torque is Vital: Always use a calibrated torque wrench for installation (e.g., $35\text{–}40\text{ ft-lbs}$ for Size 10). Over-tightening can distort the cage and cause the spool to bind.
Never Power an Unmounted Coil: Applying power to a coil when it is not installed on the valve stem will cause it to overheat and burn out almost instantly due to the lack of an inductive load.
Filtration Management: To prevent spool sticking, ensure your system is filtered to ISO 4406 19/17/14. Most “failures” in SV valves are actually caused by microscopic debris wedged in the spool clearances.
SV08-21-0-N-00
SV08-21P-0-N-00
SV08-21K-0-N-00
SV08-22-6T-N-24DG
SV08-22-0-N-00
SV08-22M-0-N-00
SV08-23-0-N-00
SV08-23P-0-N-00
SV08-24-0-N-00
SV08-25-0-V-00
SV08-28-0-N-00
SV08-28-0-V-00
SV08-30-0-N-00
SV08-30M-0-N-00
SV08-31-0-N-00
SV08-35-0-N-00
SV08-40-0-N-00
SV08-47A-0-N-00
SV08-47A-0-N-00/с
SV08-47B-0-N-00
SV08-47CM-0-N-00
SV08-47C-0-N-00
SV08-47C-0-N-24DG
SV08-47D-0-N-00
SV08-47D-0-N-00 с
SV08-47DM-0-N-00
SV10-20-0-N-00
SV10-20-0-N-24DG
SV10-20M-0-N-00
SV10-21-0-N-00
SV10-21P-0-N-00
SV10-21P-0-N-24DG
SV10-21P-0-N-230AG
SV10-22-0-N-00
SV10-22M-0-N-00
SV10-23-0-N-00
SV10-23P-0-N-00
SV10-24-0-N-00
SV10-24-0-V-00
SV10-24-0-N-12DG
SV10-24M-0-N-00
SV10-25-0-N-00
SV10-28-0-N-00
SV10-28-0-N-24DG
SV10-29-0-N-00
SV10-31-0-N-00
SV10-34-0-N-00
SV10-34M-0-N-00
SV10-40-0-N-00
SV10-40-0-N-24DG
SV10-42M-0-N-00
SV10-44-0-N-24DG
SV10-47A-0-N-00
SV10-47B-0-N-00
SV10-47D-0-N-00
SV10-47D-0-N-24DG
SV10-47DM-0-N-00
SV12-20-0-N-00
SV12-20-0-N-24DG
SV12-21-0-N-00
SV12-22-0-N-00
SV12-23-0-N-00
SV12-28M-0-N-00
SV12-29-0-N-00
SV12-29P-0-N-00
SV12-34-0-N-00
SV12-34-0-N-24EG
SV12-34-0-N-12EL
SV38-20J-0-N-00
SV16-20-0-N-00
SV16-20M-0-N-00
SV16-22-0-N-00
SV16-22M-0-N-00
SV16-23-0-N-00
SV16-23P-0-N-00
SV38-26-0-N-00
SV38-26M-0-N-00
SV38-28-0-N-00
SV38-28S-0-N-00
SV38-28P-0-N-00
SV38-38-0-N-00
SV38-38P-0-N-00
SV3-12-0P-0-00SV3-10V-C-0-00SV3-10-C-3G-230AGSV3-10-0-0-24DGSV3-10-0-00-01SV3-20-0-8G-24DGSV3-20-0-0-24DGSV3-20-0-0-00SV3-16-0P-
0-24DGSV3-16-0-0-24DGSV3-16-0-0-230AGSV3-12-C-0-00SV3-12-0S-0-12DGSV3-12-0-0-24DGSV3-12-0-0-24AGSV3-12-0-0-12DGSV3-12-0-0-00
SV3-10V-C-0-24DGSV3-10-CR- 0-24DGSV3-10-CM-0-24DGSV3-10-CM-0-00SV3-10-C-0-230AGSV3-10-0P- 0-24DGSV3-10-0-0-12DWSV2-8-4M-0-24DGS
SV2-20-C-0-24DGSV2-10-C-0-230AGSV15-8-C-0-240AGP-SV14-8-C-0-00SV14-10-0-0-24DGHSV13-12-0P-0-00SV13-10-0-0-00-01SV13-20V-C-0-240AGH
SV13-20-CM-0-24DGHSV13-20-C-M-0-00SV13-20-C-0-24DGHSV13-16-C-0-00SV13-12-C-0-00SV13-10-CM-0-00SV13-10-C-M-0-24DGHSV13-10-0-0-24DGH
SV1-16-C-0-24AGSV1-10V-C-C-0-00SV1-10V-3-0-00SV11-8-4-0-00SV11-8-3-0-24DGP-SV11-8-3-0-00SV11-10-C-0-24DGHSV11-10-C-0-00
SV11-10-4-0-240AGHSV11-10-3-0-24DGHSV11-10-3-0-12DGHSV1-8-0-0-00SV1-16C-4G-24DGSV1-16-CM-0-00SV1-16-C-6G-24DGSV1-16-C-0-24DG
SV1-16-C-0-230AGSV1-16-C-0-12DGSV1-16-C-0-115AGSV1-10-C-0-00SV1-10-4-0-00SBV12-8-C-0-00SBV11-10-0-00-01SBV11-8-C-S3G-24DGP-
SBV11-8-C-0-24DGP-SBV11-8-C-0-240AGP-SBV11-8-C-0-12DGP-SBV11-8-C-0-00SBV11-8-0-0-24DGP-SBV11-8-0-0-12DGP-SBV11-8-0-0-00
SBV11-12-C-S6G-24DGHSBV11-12-C-S6G-12DGHSBV11-12-C-0-24DGHSBV11-12-C-0-240AGHSBV11-12-C-0-00SBV11-12-0-0-24DGHSBV11-12-0-0-00
SBV11-10V-C-0-00SBV11-10V-0-A3G-24DGHSBV11-10V-0-0-00SBV11-10-C-S3G-24DGHSBV11-10-C-0-24DYHSBV11-10-C-0-24DGHSBV11-10-C-0-240AGH
SBV11-10-C-0-120AGHSBV11-10-C-0-00SBV11-10-0-0-24DGHSBV11-10-0-0-240AGHSBV11-10-0-0-12DGHSBV11-10-0-0-00
