Torqmotor TF0240LS460AAAA TF-0240-LS-46-0-AAAA Hydraulic Motor TB/TG/TF

Torqmotor TF series hydraulic motor
1. The TF series is a durable hydraulic motor with excellent lateral load capacity, high Y-axis sealing, and smooth low-speed operation characteristics, suitable for heavy-duty applications such as vehicle propulsion, auger, chain drive, winch, and boom rotation
Main technical parameters:
Displacement: 237 cm ³/rev (corresponding to the “0240” section in the model)
Shaft size: 1.25 inches
Installation method: flange or wheel hub installation
Intermittent pressure rating: 280 bar
Torque: 8100 lb in
Side load capacity: 4000 lb on flange installation and 6000 lb on wheel installation
Model description (refer to naming conventions for similar models)
TF: Motor serial number
0240: Displacement, 237 cm ³/rev
L: May represent shell type or specific design
S: May represent the port connection method
460: Axis extension code
AAAA: Standard, black paint
This service manual has one purpose: to guide you in maintaining, troubleshooting, and servicing the TF, TG, TH and TL Torqmotor™
(low-speed, high-torque hydraulic motor). Material in this manual is organized so you can work on the Torqmotor™ and get results
without wasting time or being confused. To get these results, you should read this entire manual before you begin any work on the
Torqmotor™. This manual also contains troubleshooting information and checklist. If you must service the Torqmotor™, the checklist
will help you to determine where the problem may be. The three-column format of the Disassembly and Inspection, and Assembly
sections will make it easier for you to conduct major work on the Torqmotor™. Column 1 gives a brief key for each procedure.
Column 2 explains in detail the procedure you should follow. Column 3 illustrates this procedure with photographs. Read all
material carefully and pay special attention to the notes, cautions, and warnings.
