VTOZ WDKE Solenoid Valve | WDKE-1613 WDKE-1631 | 10 Bore Directional Control

The WDKE Series from LIC Hydraulic is a premier Direct-Acting Solenoid Valve engineered to ISO 4401 Size 10 standards. Known for their high pressure and high flow capabilities, models like WDKE-1713-24DC and WDKE-1631 feature specialized “wet” solenoids that provide superior shifting performance and thermal stability. These valves are the industry choice for demanding environments where precision and reliability are paramount. We offer 100% drop-in replacements, ensuring consistent flow dynamics and electrical compatibility with your existing systems.

Technical Highlights

• Standard: CETOP 5 / NG10 / 10 Bore.

• Max Operating Pressure: $350\text{ bar}$ ($5075\text{ psi}$).

• Max Flow Rate: Up to $150\text{ L/min}$ ($39.6\text{ GPM}$).

• Coil Type: High-performance, waterproof, and heat-resistant DC/AC solenoids.

Core Advantages

• Low Pressure Drop Design: The 5-chamber valve body cast maximizes the internal flow path, allowing for high volume movement with minimal energy loss.

• Durable Wet-Pin Solenoids: With the plunger moving in oil, the WDKE series offers dampened shifting that reduces wear and extends the service life of both the valve and the electrical coil.

• Precise Spool Alignment: Lapped to micron-level tolerances, our spools provide predictable and repeatable shifting times, essential for automated machinery.

• Versatile Connectivity: Available with various connector types including DIN plugs with optional status LEDs for simplified on-site troubleshooting.

Expert Maintenance Tips

• Mounting Torque: When installing the WDKE valve on a subplate, use high-grade 12.9 bolts and torque them evenly to $8.9\text{–}9.5\text{ Nm}$. Uneven torque can distort the valve body and cause the spool to stick.

• Voltage Check: For the 24DC version, ensure your power supply delivers a minimum of $22.8\text{V}$ under load to guarantee reliable shifting against high hydraulic forces.

• O-Ring Care: During replacement, always use a light coat of clean hydraulic oil on the interface O-rings to prevent pinching or tearing during the mounting process.
